White Label B700 Top Mount Single Lever Engine Control With Trim And Tilt

Easy instinctive action with positive detent for shifts

The B700 Top Mount Control range are dual function
controls suitable for use on inboards with hydraulic gearboxes,
outboards and stern drives.

B700 Top Mount Control Features:

• Each lever operates both shift and throttle
• Easy instinctive action with positive detent for
  shifts
• Adjustable throttle friction
• Push button disengagement of shift for neutral throttle warm
  up
• Can only shift at low RPM thereby protecting gearbox
• Optional trim/tilt control
• Dual station capability (requires exchangers)
• Optional neutral safety switch to ensure engine start can only
  occur when in neutral

B700 Top Mount Control Specifications:

• Accepts universal 30 series cables, CC172, CC330, CC633, 33C
  and SP33C
• Diecast zinc alloy frame
• Gold passivated steel link plates
• High impact ABS dress covers
• Optional neutral safety switch: 301025

Note: No actuators included.
