White Label Linkable SunStar Solar Charge Controller 60A 12-48V

The professional grade, high current Linkable SunStar Solar
Charge Controllers 60A 12-48V offer the flexibility to
suit almost any solar installation. System voltage can be 12, 24 or
48V, and multiple units can be stacked together (up to 10 units
max) allowing your system to grow and expand without rendering your
old charge controller useless. Each unit features an LCD and front
panel controls, and can be used as either a battery charger, load
controller or diversion regulator. They can also be connected to a
remote control for remote monitoring, and are fully protected
against reverse polarity, short circuit, high temperature and
overvoltage. Particularly suited to the SuperCombi and CombiPlus
units, as they communicate via data cables to exchange charging
information.

Linkable SunStar Solar Charge Controller 60A 12-48V
Specifications:

• System voltage: 12 – 48V
• Max solar voltage: 140V
• Max. operating voltage: 68V
• Parallel connection (x 10 units): Up to 600A
• Min. voltage to operate: 9V
• Power Consumption: 25mA while operating, 3mA when idle (inc.
  LCD)
• Operating ambient temp: -40C – 70C
• Cutout solar @ 90C
• Cutout load @ 70C
• Reconnect solar @ 70C
• Reconnect load @ 50C
• Humidity: 100% non-condensing with conformal coating on both
  sides of all PCBs
• Largest wire: 35mm^2 / 2GA
• Enclosure: type1, indoor rated
• Weight: 2kg
• Dimensions: 266(L) x 127(W) x 75(H)mm

Note: Requires data cable (WI-5250, WI-5252,
WI-5254) for parallel stacking or connection to
SuperCombi/CombiPlus units.
